LD-002H Mono LCD Resin 3D Printer
Creality LD-002H, the new upgradable resin 3d printer redesigned by LD-002R, but with130*82*160mm large building volume, allows you to print more different sizes of models. adaptable for dental modules & samples, suitable for 3d printing business start-ups and 3d printing manufacturers.
Upgrade UV Light Source Module: The Creality LD-002H is equipped with a UV integrated light source, providing improved light transmission. The UV light achieves 8000uw/cm². A consistent UV light source is the most important factor in printing.
Z-axis Linear Rail: The linear rail provides a much stronger structural mechanism for the Z-axis, resulting in better, more refined prints.
Air Filtration System with Activated Carbon: Activated carbon can effectively reduce the emission of the odor from resin and is more environmental-friendly.
Easy Leveling System: Simply lower the printing platform atop an ordinary piece of paper. Then hand tighten the leveling nut to complete the leaving process.
Powerful Slicer Software: The Creality LD-002H resin printer is supported by CHITU BOX software for slicing. CHITU BOX is easy to use, with one-key functions to add a model, adjust supports, model size, etc.
3.5 Inchi Full-color Touch Screen: A simple UI design interface can monitor real-time printing information, is easy to operate, and user-friendly.
NEW ITEM: Hi-Res 6.08” 2K monochrome screen: The Creality LD-002H utilizes a 1620*2560 monochrome LCD for layer exposure. Not only does it increases print speed up to 200% or more, but the life of the screen is increased by up to 400%.
LD-002R & LD-002H Parameter
Printer | LD-002R | LD-002H |
---|---|---|
LCD Size | 5.5 inch RGB LCD | 6.08 inch Mono LCD |
Molding Size | 119X65X160mm 4.69x 2.56 x 63inch | 130x82x160mm 5.12x3.23x6.3inch |
Resolution | 1440*2560 | 1620*2560 |
Curing time | 6-18s/layer | 1-4s/layer |
Layer Height | 0.01-0.05mm | 0.03-0.05mm |
XY-axis Precision | 0.075mm | 0.051mm |
Touch Screen(3.5") | √ | √ |
